Sockel* |
S1366 |
Unterstütze Prozessoren* |
Core i7 Processor Extreme Edition/Core
i7 Processor |
Chipsatz* |
Intel X58 / ICH10R |
Bauform-Standard* |
Micro ATX |
Anzahl Speicherbänke* |
6 |
Speicherart (MHz)* |
DDR3 2000/1800/1600/1333/1066 |
max.
Speicherbestückung (GB)* |
24 |
Onboard-VGA* |
Nein |
Onboard-VGA Anschlüsse |
Nein |
Steckplätze PCI (32 Bit)* |
1 |
Steckplätze PCIe x4* |
1 |
Steckplätze PCIe x16 V2.0* |
2 |
USB2.0-Anschlüsse* |
6+6optional |
FireWire-Anschlüsse* |
1+1optional |
eSATA* |
1 |
Floppyanschluss (für Diskettenlaufwerk)* |
Nein |
IDE-Anschlüsse* |
1 |
IDE-Standard* |
133/100/66 |
SATA
1/2-Anschlüsse* |
SATA2 (3.0 Gb/s) 6x |
SATA
1/2-Raidfunktion* |
0, 1, 0+1, 5 |
Chipsatz Raidcontroller* |
Intel Matrix Storage Technology |
Netzwerk1-Chipsatz* |
Realtek |
Netzwerk1-Datenrate (Mbits)* |
10/100/1000 |
Onboard-Sound* |
|
PS/2-Anschlüsse* |
1 |
Serielle Anschlüsse* |
Nein |
Parallele Anschlüsse* |
Nein |
|
